RAD-HARDENED
VA53230
Dual Core Arm® Cortex®-M55 Microcontroller
Accelerated Dual Core Performance
The radiation-hardened The VA5 family represents VORAGO’s first generation of dualcore Arm® Cortex®-M55 microcontrollers, available in both radiation hardened by process (RHBP or HARDSIL® technology) and radiation tolerant by design (RTBD) versions. Purpose-built for the extreme demands of space, defense, and autonomous missions, these space-grade MCUs combine dual 32-bit cores with robust radiation mitigation, advanced fault tolerance, and power-efficient processing.
Specifications
Engineered for extreme environments, the VA53230 is targeted to run up to 200 MHz with ECC-protected program and data memory for high-throughput, low-latency computation - ideal for onboard payload control and spaceflight avionics.
-
TID >200 krad(Si)
SER: < 1E-15 errors/bit-day
SEL >110 MeV*cm2/mg
-
Core: 1.2 V ± 10%
I/O: 3.3 V ± 10%
-
512KB double word and 128KB byte SRAM
each with EDAC and Scrub Engine
256KB in-package NVM for boot using SPI
256B Persistent Memory
8/16/32-bit External Bus Interface (EBI)
-
2xADC-12bit, 4xDAC-12bit (2 external, 2 internal)
8x Analog comparators
2x Motor Control Tool-Box (timers, PWM, ADC HW triggers)
-
32x Timers/Counters with PWM, 2x
Watchdog Timers, 136 GPIO, 3.3 V
-
-55° to 125°C
-
• 256-pin Ceramic QFP
• 256-pin Plastic QFP
• 313 Plastic BGA
-
Advanced ADCS & Robotics
Propulsion Management
Precision Payloads
Secure Space
Networking
Software-Defined
Radios (SDR)
Autonomous Aviation & Flight Control
One Design
One Design, Two Radiation Profiles
RAD-TOLERANT
Meet the VA54230, the radiation-hardened twin to the VA53230
Prototype on the VA54230, then deploy the VA53230 in the same footprint for Medium Earth Orbit, Geosynchronous Earth Orbit, and deep space.
